eMPAGE 16-zone | 20-key | e-ink display | RJ45

Περιγραφή

eMPAGE is a digital paging station (MPAGE16's evolution), compatible with HUB, MIMO88, MIMO88SG and MIMO1212SG digital matrixes. Includes: a gooseneck cardioid microphone (removable); 16 zone-selection keys; ALL, CLEAR and PAGE keys; 2 programmable keys, F1 & F2, for zone-group selection. Text labelling for destination areas by means of programmable electronic ink display.

20 mechanical keys with integrated LED status indicator (paging zone selection management)

1 mechanical key with adjacent LED indicator (message activation, PAGE key)

Electronic ink display (shows paging zone names)

Gooseneck microphone, with standard XLR connector

Management of up to 16 paging zones

RJ45 connector for single CAT5 or higher cabling (point-to-point), including power, audio output signal (picked up by the microphone) and digital control bus between the HUB unit and the eMPAGE station

Connector for backup power supply (optional)

Two eMPAGE units, with different or equal priority levels, can work simultaneously on the same HUB zoner

Programming of paging station(s) functionality from the web application embedded in the HUB: enabled paging zones, chime melodies, priorities, programmable keys, etc.

Number of output channels	1 (picked up by the microphone)
Number of paging zones	16
Microphone type	Removable gooseneck condenser microphone (eMCN1)
Polar pattern	Unidirectional
Frequency response	50Hz – 18KHz (-10dB)
Phantom power	48VDC, always ON
Input connection type	XLR female conection type
Resolution	296x128 Pixels
Display	Active Matrix Electrophoretic Display
Touch-panel	No
LED indicators	Green LED on All and Clear keys, Bicolor LED on other keys
Buttons	Paging zone selection keys, PAGE key, F1, F2, All & Clear keys
Ethernet	1 RJ45 connector, cable: Cat-5 or better. Supports PoE
Programing and control	RS485 and CAN, internally selectable by JUMPER
Power supply	Optional, 24VDC (min. 80mA) Recommended external power supply: Ecler WP24-PSU
PoE	Yes
AC mains requirement	From RJ45 remote input: 12VDC From External Input: 24VDC (With WP24-PSU backup power supply)
Max power consumption	From RJ45 remote input: 180mA From External Input: 180mA
Type	Paging station
Installation options	Desktop
Operating temperature	Min: -10°C ; 14°F Max: 40°C ; 104°F
Operating humidity	<85% HR
Storage temperature	Min: -10°C ; 14°F Max: 40°C ; 104°F
Storage humidity	<90% HR
Included accessories	Windscreen for Microphone, jumper for internal connection and RJ45 to Euroblock adapter
Dimensions	150 x 50 x 180 mm / 5.91 x 1.97 x 7.09 in. (WxHxD) (microphone excluded)
Weight	0.9 kg / 1.98 lb
