eMCONTROL1 Digital remote control | LCD | HUB compatible

Κωδικός Προϊόντος: 1.045.139

Διαθεσιμότητα: Διαθέσιμο

eMCONTROL1 Digital remote control | LCD | HUB compatible

Περιγραφή

eMCONTROL1 is a digital wall control compatible with HUB Series and eMIMO1616 and configurable through the web application embedded. It allows you to configure source selection, volume control and equalization for a given zone, including all or some of the functions. It can be combined with a WPa series wall panel, connecting both with a single CAT5 cable or better to the HUB digital zoner, transmitting the mono and balanced audio signal (line level) along with the necessary control data and DC power supply.

Digital control panel compatible with HUB Series and eMIMO1616

Volume adjustment, source selection and EQ (programmable)

Compatible with WPa series panels with audio connector, for sending audio and control signals over a single CAT5 cable or better

Styling designed in collaboration with Italdesign Giugiaro

Resolution	128x128 pixels
Display	LCD
Buttons	Encoder, selection key
Ethernet	1 RJ45 connector, cable: Cat-5e or better
Serial port	RS-485
Programing and control	Configurable through the web application HANGAR
Power supply	Optional, 24VDC (min. 30mA) Recommended external power supply: Ecler WP24-PSU
Type	Source selection, volume control, equalization
Installation options	Wall
Operating temperature	Min: -10°C ; 14°F Max: 40°C ; 104°F
Operating humidity	<85% HR
Storage temperature	Min: -10°C ; 14°F Max: 40°C ; 104°F
Storage humidity	<90% HR
Included accessories	Cable to interconnect with WPaMIX-T, Screws for fixing to surface or flush mounting box, Magnet for cover removal, Surface mounting box
Dimensions	86 x 86 x 45 mm / 3.39 x 3.39 x 1.77 in. (WxHxD)
Weight	0.15 kg / 0.33 lb
Shipping dimensions	120 x 220 x 80 mm / 4.72 x 8.66 x 3.15 in. (WxHxD)
Shipping weight	0.3 kg / 0.66 lb
