LINEAR 5 MK II 118 Sub HPA

Max. SPL @ 10% THD

130 dB half space (36 Hz – 100 Hz averaged)

Max. SPL peak @ 10 % THD

131 dB half space

Frequency response +/-3 dB

36 Hz – X-over

Frequency response -10 dB

33 Hz – X-over

Power amp output (rms/peak)

1,500 / 3,000 W

Amp type

Class D

LF driver

1x 18", 4" voice coil

Low-/mid speaker

-

HF driver

-

Horn directivity

-

Active crossover frequency

-

Maximum input level

+20 dBu

Analog inputs

2x XLR combo balanced

Analog thru

2x XLR balanced

DSP Out

1x XLR balanced

Network port

Ethercon RJ45, 1x In, 1x Thru

Filter presets

Front, Cardioid 1:1 vertical, Cardioid 2:1 vertical, Remote

Remote software

DSP CONTROL (Windows, Mac OS)

DSP functions

Fully parametric 10-band EQ with variable filter characteristics, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute

Sample rate

48 kHz

System latency

<= 2.6 ms

Mains connector

1x Powercon NAC3 In, 1x Powercon NAC3 Thru, 100–240 V

Power consuption

2.5 A / 100–240 V nominal according to EN 62368-1

Angels up (Monitor angle)

-

Pole mount

1x M20

Rigging points

-

Carrying handles

4x HK Audio MultiGrip

Housing

Birch multiplex

Finish

Black acrylic enamel

Front grille

2 mm metal grille backed with black acoustic foam

Dimensions (WxHxD)

60 x 60,8 x79 cm 23-5/8 x 23-15/16 x 31-7/64"

Weight

56,8 kg / 125,22 lbs
